A simple circuit showing voltage source, current and resistor
Battery drives a current through a resistor

Ohm's law

Ohm’s law was discovered by Georg Ohm in 1837 and it is the basic equation that governs a lot of circuitry. The three main ingredients are the current through a simple circuit, the voltage applied (typically by a battery), and the resistance of a device which uses the current to produce some work, typically heat or light.

In this step, you will learn about

  • the mathematical formulation of Ohm’s law and the basic inverse relation that it encodes

  • how a water pipe analogy can help in understanding the meaning of Ohm’s law.

Ohm’s law

Ohm’s law states that if is the voltage (measured in volts) across a resistor (measured in ohms) which draws a current (measured in amperes), then

A resistor is an object that uses electrical power and converts it to something else, perhaps heat or light. A toaster is an example. The electricity that runs through a toaster is powered by a voltage differential, supplied by the electrical power outlet. The greater the voltage, the more current runs through the toaster. So for a fixed resistor , Ohm’s law establishes a linear proportionality between voltage and current.

Picture of hot, red toaster filaments Toaster Filaments Nick carson at en.wikipedia CC BY 3.0, via Wikimedia Commons

However we can look at the law in other ways. If we regard the voltage as fixed, then the resistance and current are inversely proportional, since their product is constant and equal to the fixed voltage. If we increase the resistance, then the current decreases, while if we decrease the resistance, then the current increases.

This is the situation with a circuit run by a battery, or with the electricity in our house, where the voltage supplied is constant ( volts in most of the Americas, volts in Europe, Australia and most countries in Asia). However strictly speaking in this case the voltage is alternating in direction.

In the limiting case where the resistance becomes zero, for example if you replace the toaster with a wire, then an indefinitely large current flows. Then a short erupts, often with disastrous consequences, particularly if you don’t have a fuse connected to break the circuit in such an emergency situation.

Some examples

If we connect a lamp to a circuit run by a 6 volt battery, and draw a current of 3 amps, then the resistance is given by

Now if we connect that same lamp to a 10 volt battery, then the current will be

If we want to make the light brighter we need to increase the current, let’s say to 8 amps then we need to increase our voltage to

Q1 (E): An electrical device is connected to 120 volts. Find the current if the resistance is 480 ohms.

Q2 (E): Suppose that we have a battery of some constant voltage lighting a small lamp, and an ammeter reads 40 mA, where mA stands for milliamps, which are one thousandths of an amp. If the current drops to 20 mA, what has happened to the resistance?

How does a resistor resist?

A resistor is any device that slows down the flow of current in a circuit. Electricity is essentially moving electrons, and much like water, if the flow is interrupted, restricted or resisted, less gets through. Some materials have low resistance, such as copper wire, which allows electrons to flow through it without much trouble at all. Other materials, such as wood, have high resistance, stopping electrical flow almost immediately. In practice we have things like lamps and toasters that generate light or heat from the electrons, slowing them down, but still letting them through.

Ohm also discovered another law, that describes how much resistance a given material, such as a piece of wire tube, has:

where is the length of the resistor, is a quantity that depends on the material, and is the cross-sectional area of the resistor. So is directly proportional to the length : double the length of the wire tube and its resistance doubles. But is also inversely proportional to the cross-sectional area : double the area and the resistance halves.

Q3. (E): A tubular resistor is in the shape of a wire. If we triple its length and halve its diameter, what happens to its resistance?

A hydraulic analogy

In order to understand Ohm’s law, a hydraulic analogy for beginners is sometimes useful. Imagine water flowing through a horizontal pipe. The water pressure is analogous to voltage because it is a pressure difference between two points along the pipe that causes water to flow. The actual water flow rate is then the analogue of current .

What about the analogue of a resistor? That can be imagined as something which obstructs the flow of water, such as restrictions or apertures placed in the pipes. If the water is forced through a very thin tube, then the longer the tube and the smaller its cross-sectional area, the greater resistance it will have on the water flow rate . And the greater the resistance, the less the flow.

The relevant equation for our hydraulic analogue is, in appropriate units,

So if we keep the pressure fixed, then the flow rate and restriction will be inversely proportional: as the size of a restriction decreases, the flow rate must increase.

In the figure below, we would expect that the thinner tube would act like a resistance to the flow in the large tube.

Diagram of flowing through a long pipe with narrow and thick sections Bernoullis Law Derivation Diagram by MannyMax CC-BY-SA-3.0, via Wikimedia Commons


A1. By Ohm’s law we can find the current by

A2. When the voltage is constant, the relation between the current and the resistance is inverse. Therefore, if the current halves, the resistance doubles.

A3. Tripling the length of the resistor increases its resistance by a factor of 3, while halving its diameter multiplies the cross-sectional area by 1/4. Overall the resistance changes by a factor of .
